SKU: AJ833A Categorie:

183,60 lei

Stoc epuizat

    Adaugă produse în sumă de 500,00 lei pentru a beneficia de transport gratuit!
    315 People watching this product now!

    Peste 20.000 produse

    Actualizate la zi

    Suport tehnic

    La nevoie

    Transport rapid!


    Garanția calității EXPERT IT!

    din 2007



    • Obsolete Date 30-06-2021
    • End of support date 30-06-2026


    • Weight 0.45 kg
    • Weight 1 lb
    • Product dimensions (H x W x D) 0.5 x 12 x10 in
    • Technical notes Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end. Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um Coating diameter: 245 ± 10um Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km @850/1300nm. Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km @850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links. CABLE: The cable is duplex zipcord graded index 50/125um multimode optical fiber and designed to work in both the 850 and 1300 nm wavelength windows. BULK CABLE & CABLE ASSEMBLY CONFIGURATION: Jacket Material: Riser Grade – Low Smoke Zero Halogen thermoplastic. Jacket Color: Aqua for OM3 multimode per TIA 598 Boot Color: White Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M added for lengths > 30 meters. Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310 nm @ 23°C as tested in accordance with EIA 455-46. Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
    • Minimum dimensions ( H x W x D) 1.27 x 30.48 x 25.4 cm
