| Chipset | |
| Producator chipset |
AMD
|
| Seria |
Radeon RX 6000
|
| Tehnologie de fabricatie |
7 nm
|
| Procesor grafic |
Navi 22
|
| GPU Boost clock |
2618 MHz
|
| Data lansarii chipset |
18.03.2021
|
| Shader Model |
6.5
|
| Texture Units |
160
|
| Raster Operators |
64
|
| Stream Processors |
2560
|
| Profiluri OC | |
| Frecventa GPU Boost mod OC |
2618 MHz
|
| Memorie | |
| Tip memorie |
GDDR6
|
| Dimensiune memorie |
12 GB
|
| BUS memorie |
192 bit
|
| Frecventa memorie efectiva |
16000 MHz
|
| Infinity Cache |
96 MB
|
| 3D API | |
| Suport DirectX |
12 Ultimate
|
| Suport OpenGL |
4.6
|
| Suport OpenCL |
2.0
|
| Suport Vulkan |
Da
|
| Suport FreeSync |
Da
|
| VR Ready |
Da
|
| Porturi | |
| HDMI |
1
|
| Display port |
3
|
| Racire | |
| Sistem racire |
Activ
|
| Dimensiune racire |
Tri slot
|
| Tip racire |
Aer
|
| Altele | |
| HDCP Ready |
Da
|
| Tehnologii |
AMD RDNA™ 2 Architecture
DirectX® 12 Ultimate Hardware Raytracing 7nm GPU GDDR6 Memory PCI® Express 4.0 Support AMD FreeSync™ Technology DisplayPort™ 1.4 with DSC HDMI™ 2.1 VRR Video Streaming up to 8K Radeon™ VR Ready Premium AMD FidelityFX Radeon™ Image Sharpening Radeon™ Anti-Lag Radeon™ Software Game Driver Optimizations |
| Alimentare separata |
1x 6-pin PCI-E, 1x 8-pin PCI-E
|
| Dimensiuni |
280 x 122.75 x 50.47 mm
|
| Backplate |
Da
|
